XY Stage 25mm 500µm

The Owis model VT45-25-XY is a translation stage that provides 25 mm of travel and 500µm of resolution. It has fine-thread spindles with graduated button which enables sensitive adjustment. The spec. sheet contains its complete technical data and features. The VT45-25-xy is designed for general lab motion control applications. It is used for applications that involve adjustment in classical optical setups with columns and pins. This model is ideal for positioning CCD cameras and other opto-electronic sensors. It can be mounted without the use of mounting angle. The VT 45 translation stages features pre-loaded springs making it backlash-free. This stage enables sensitive adjustment because it contains fine-thread spindles with pitch of 0.5 mm.
