Linear Stage 2mm, 150µm Pitch

Siskiyou 50.5cr-T and 100.5cr-T series provide a travel range of 2 mm and a 150μm resolution with a 100TPI adjustment screw. The 50.5cr-T model version has a maximum horizontal axis load of 3 lb and 50.5cr-T model version has a maximum horizontal axis load of 7 lb. These models feature very precise adjustment because of its effective thread pitch of 170. These stages version can provide many degrees-of-freedom in a small volume. 50.5cr-T and 100.5cr-T series can be stacked to create XY versions, while XYZ is available by adding an angle bracket and using an end drive cr-series stage. A non-influencing foil lock feature of this model guarantees that the first adjust¬ment is also the last.
