532nm, 60µJ Picosecond Laser

Teem Photonics HNG-50F-100
532nm Picosecond Laser
60µJ Pulse

Typical Specifications:
- Wavelength: 532nm
- Repetition Rate: >45kHz
- Constant Pulse width range (FWHM): <0.65ns
- Output power: >3W
- Output energy: >60μJ
- Peak Power: >100kW
- Short term (10min) power stability: <±2%
- Long term (6 hrs) power stability: <±5%
- Beam profile: Gaussian TEM00

Description:
Q-switched laser from teem photonics. Key features include ultra-short pulses down to 550ps@50kHz,
Excellent beam quality – TEM00, M2<1.1,
Efficient, air-cooled with a Sealed package, extremely long life. Applications for the picosecond laser include Micromachining, Laser Induced Breakdown Spectroscopy, Raman spectroscopy, Supercontinuum generation and biophotonics. Q-switched laser average output power up to 100kW with pulse energy up to 60µJ at a wavelength of 532 nm.
