1064nm, 15 µJ Picosecond Laser

Teem Photonics ANP-70F-100
1064nm Picosecond Laser
15 µJ Pulse

Typical Specifications:
- Repetition rate up to 100kHz
- Ultrashort pulses down to 500ps
- Average power up to 2W
- Excellent beam quality – TEM00, M²<1.1
- Efficient, air-cooled, very compact

Description:
Q-Switched Laser from Teem Photonics with picosecond pulse output. Key features of the picosecond laser include Repetition rate up to 100kHz, Ultrashort pulses down to 500ps, Average power up to 2W and Excellent beam quality – TEM00, M²<1.1. Laser is compact air cooled and efficient. Applications for the laser are Material processing, Seeder for high power laser, Instrumentation and Biophotonics. Q-switched laser output energy up to 15 µJ at a wavelength of 1064 nm.
