Chirped Fiber Bragg Grating

Request Quote   Ships: Request a Quote for Current Ship Date | Model FPG-CHIRPED

Key Features
  • Optical Connector: Bare fiber, FC/APC, LC/APC, Custom
  • FBG Pigtail Length: 0.5 meters (Custom Available Upon Request)
  • Wavelength range: 600nm to 2300nm (Specify)
  • Types of Fiber: Single-Mode, PM, Double clad, LMA, Custom

Customers Also Considered:

MODEL FPG-CHIRPED
PRICE Request Price

Product Overview:

The Chirped FBG has linear variation of the FBG period along the grating length. Chirped FBG is manufactured by using non – periodic phase mask. Available chirp rate of the phase mask period is 0.01nm/cm – 30nm/cm. Therefore such FBGs have wide spectrum bandwidth and special dispersion characteristic. Chirped FBGs are useful for gain flattening EDFA and ASE light sources, band stop filters, in ultrafast mode – locked fiber lasers, powerful laser and chromatic dispersion compensation telecom systems. The optical spectrum of high reflection Chirped FBG for powerful fiber laser is presented in the graph.
