800nm, 0.5J Femtosecond Pulse Laser

Amplitude Lasers Pulsar PW
800nm Femtosecond Laser
0.5J Pulse

Typical Specifications:
- Repetition Rate (Hz): 1-5
- Energy Per Pulse (J): > 0.5
- Pulse Width (fs FWHM): < 25
- Nanosecond Contrast: > 10^3 : 1 beyond 1 ps
- Picosecond Contrast: > 10^6 : 1 beyond 5 ps
- Pointing Stability (μrad RMS): < 25
- Max Total Electrical Power: 20 to 40 kW
- Max Water Cooling Capacity: Depends on model
- Laboratory Temperature Range: 18 - 23 ºC
- Laboratory Temperature Stability: +/- 1 ºC

Pulsar 800nm Ultrafast High Intensity Pulse Laser
Pulsar PW is the ultimate light source dedicated to high field science, offering the best-in-class performance and bringing industrial-grade reliability to science. Drawing on our large portfolio of pump lasers and solutions for effective thermal management, the Pulsar PW systems are designed for low (1 shot/min to 0.1 Hz) or high (1 - 5 Hz) repetition rates.

Pulsar PW comes with an embedded, flexible, and user-friendly monitoring and control software to further enhance the user experience and long-term reliability. The system versatility is augmented by a large offer of instrumentation and options for user specific needs.
