1064nm, 50W Picosecond Laser

neoLase neoMOS Pico
1064nm Picosecond Laser
50W Output Power

Typical Specifications:
- Pulse duration <10 ps
- Seed Laser Modelocked Fiber Oscillator
- Average power 7 / 25 / 50 W
- Repetition rate Single shot to 40 MHz
- Max. pulse energy 150 μJ @ 1064 nm (higher energy on request)
- Beam quality TEM M²<1.3 / >85 % circularity
- Power noise <1 % RMS
- Polarization ratio >100:1
- Warm-up time <30 min

Description:
The neoMOS picosecond laser series combines the reliability and low maintenance of state of the art picosecond oscillators with a solid-state amplifier. The ultra-compact laser head has the smallest footprint currently available enabling easy system integration. High stability and long lifetime are provided by design for 24/7 industrial use.

The multi-megawatt level peak-power and ultrafast pulses delivered by the neoMOS series are suitable for processing the most demanding materials including transparent glasses and plastics. Typical applications include photovoltaic and electronics production, display glass processing as well as security and decorative marking.
