1064nm, 3200W Nanosecond Laser

Powerlase Photonics Model Rigel i3200
1064nm Nanosecond Laser
3200W Output Power

Typical Specifications:
- Center wavelength: 1064nm
- Pulse repetition: 20 kHz
- Average power: 3160W
- Pulse energy: 158 mJ
- Pulse duration: 105ns
- Divergence: 12 mrad

Description:
High power nanosecond IR laser from Nanosecond Laser designed for industrial applications in Material and Photovoltaic Processing, Thin Film Removal, Rapid Laser Patterning and Extreme Ultraviolet (EUV) Generation. Key features of the industrial laser include M2=30, Excellent Stability and Condition Monitoring. The laser options include fiber delivery either round or square, computer controlled attenuation and Repetition Frequency Optimization. Pulse energy up to 250mJ with average power up to 3.2kW with a power stability of 0.3% 1σ. DPSS nanosecond laser with output wavelength of 1064nm.
