355nm, 30W Nanosecond Laser

Spectra-Physics Talon 355-30
355nm Nanosecond Laser
30W Output Power

Typical Specifications:
- Wavelength: 355 nm
- Power: 15 W @ 50 kHz; 20 W @ 50 kHz; 30 W @ 100 kHz; 21 W @ 200 kHz; 11 W @ 300 kHz
- Repetition Rate: 0 to 500 kHz
- Pulse Width: <25 nsec @ 100 kHz

Description:
Q-switched laser with nanosecond output pulse from Spectra-Physics. Applications for nanosecond laser are PCB de-paneling, cutting, and drilling; Solar cell processing; Silicon scribing; Ceramic scribing, cutting, and drilling; Glass cutting and drilling; and Metal foil cutting.
Laser was designed for industrial applications and features an easy-to-integrate compact laser head with the diodes and control
electronics, and simple utility hookups. For reliable operation the Q-switched laser features an ALPS cavity cleanliness control system and carefully selected laser diodes provides a long lifetime. Q-Switched laser with wavelength of 355nm and output power of 30 watts.
