1064nm, 5mJ Nanosecond Laser

Lee Laser Co. Model LDP-100MQG
1-64nm Nanosecond Laser
5mJ Pulse

Typical Specifications:
- Wavelength: 532 nm
- Transverse Mode: Multimode
- Beam Diameter, nominal: < 2.0 mm
- Beam Divergence, nominal: 4.0 mr
- Polarization: Linear
- Q-switched performance:
- Frequency (kHz): 5, 10*, 20
- Average Power (W): 40, 50*, 48
- Pulse Energy (mJ): 8, 5.0*, 2.4
- Pulse Width (ns), nominal: 150, 200*, 325
- Peak Pulse Power (kW): 53.3, 25*, 7.4

Description:
Nd:YAG Laser with nanosecond pulse output up to 5mJ at a wavelength of 1064nm. Q-Switched laser with frequency 10kHz and pulse energy of 5mJ at a pulse width of 200ns. Higher pulse energy up to 8mJ is possible at a frequency of 5kHz. At 10kHz maximum peak pulse power is 25,000 watts. Nd:YAG laser was designed for demanding industrial applications and is known for reliability and ruggedness. Integrated power supply and use of diode pump lasers provides for long laser lifetime.
