1064nm, 1650mJ Nanosecond Laser

Continuum Inc. Powerlite DLS 8010
1064nm Nanosecond Laser
1650mJ Pulse

Typical Specifications:
- Repetition Rate (Hz): 10
- Energy (mJ):
- 1064 nm: 1650
- 532 nm: 800
- Pulsewidth (nsec):
- 1064 nm: 6-8
- 532 nm: 5-7
- Linewidth (cm-1): Standard 1

Description:
Continuum distributed intelligence, with microprocessors in both the laser head and power supply for more precise system control. Rack mounted and modular components for easier maintenance and service. Active digital control for acurate temperature monitoring and improved thermal management. Standard, powerful Windows®-based Graphical User Interface for complete control of all system
functionality. LabView drivers are available. Divergence: 0.45 mrad, Beam Pointing Stability ±30µrad, and Beam Diameter 9mm. High energy Nd:YAG laser output up to 1650mJ at a wavelength 1064nm.
