532nm, 10W Picosecond Fiber Laser

Spark Lasers ANTARES-GR
532nm Picosecond Laser
10W Output Power

Typical Specifications:
- Wavelength: 532 nm or 515 nm
- Spectral width: < 1 nm
- Pulse duration: < 10 ps
- Max. average power: 10 W
- Repetition rate: 80 MHz
- M²: < 1.2
- Beam waist diameter: 1 mm
- Beam pointing: < 25 μrad/°C
- Ellipticity: > 0

Description:
Fiber laser with picosecond pulse output from Sparks Laser. The laser was designed for applications in pumping of OPO, semiconductor industry, and medical & bio-medical. Factory configurable pulse repetition rate up to 80MHz with a pulse duration of 10ps. Narrow linewidth output beam with diameter of 1mm and beam quality of M2<1.2. Fiber laser was designed for easy integration using plug-play technology and has rugged compact design. Laser is also maintenance free for low cost of ownership. Fiber laser output is 532nm with up to 10 watts of average power.
