1064nm, 100nJ Picosecond Laser

Ekspla LightWire FP200
1064nm Picosecond Laser
100nJ Pulse

Typical Specifications:
- Central wavelength: 1064 nm
- Pulse duration: < 9 ps
- Spectral bandwidth: < 0.4 nm
- Pulse repetition rate: 30 kHz – 30 MHz
- Output power:
- > 200 mW at 10 MHz
- > 50 mW at 1 MHz
- > 10 mW at 100 kHz
- Pulse energy: > 100 nJ at repetition rate of < 200 kHz
- Polarization: linear, > 100:1 extinction
- Optical output: 0
- Fiber length with collimator: 3 m
- Beam quality: m² < 1.1

Description:
Fiber laser from Ekspla with picosecond pulse output. Applications for the picosecond laser include seeding solid state amplifiers, ultrafast spectroscopy and microscopy. Integrated fiber pulse picker provides flexible repetition rate control from 30 kHz to 30 MHz and burst mode is available. Pulse duration is less than 8ps. Beam quality of the fiber laser is M2<1.1 with a spectral bandwidth less than 0.4 nm. Output energy ranges from 200mW to 10mW over a pulse repetition rate of 10MHz to 100kHz respectively. Fiber laser output energy is 100nJ at a pulse repetition rate greater than 100kHz at a wavelength of 1064nm.
