1030nm, 20W Picosecond Laser

YSL Photonics PicoYL-30-100-20
1030nm Picosecond Laser
20W Output Power

Typical Specifications:
- Wavelength: 1030nm
- Average Power: ~20W
- Repetition Rate: 25-1000kHz
- Power Stability: <2%
- Pulse Energy: >30uJ@100ps or >300uJ@1ns
- Peak Power: 300kW
- Pulse Duration: 100ps-4ns
- Switch On/Off Time: <5us
- Beam Quality: M2 <1.3
- Beam Diameter: 6.5mm
- Beam Divergence: <1mrad
- Output Polarization: Linear Polarized
- Trigger: SMA
- Supply Power/Current: DC24V/8A

Description:
Fiber laser from YSL Photonics has the following key features 100ps Pulse Duration, Peak Power up to 300kW, Repetition Rate 25kHz-1MHz and Burst Mode Function. Picosecond Fiber laser applications include LED Sapphire Substrate Dicing, Lion Ion Battery Foil Cutting, Thin Film Solar Cell Scribing, Silicon or SiC Dicing, Metal Marking, Chrome Vanadium Texturing, and Micromachining of Transparent materials. Beam quality of M2<1.3 with a beam diameter of 6.5mm and divergence of <1mrad. Fiber laser output pulse energy 300μJ at 1ns or 30uJ at100ps with average output power of 20 watts at a wavelength 1030nm.
