1030nm, 200µJ Picosecond Laser

Amplitude Laser Tangerine HP
1030nm Picosecond Laser
200µJ Pulses

Typical Specifications:
- Average Power: > 35 W
- Pulse Width: < 150 fs
- Central Wavelength: 1030 nm +/- 5 nm
- Energy Per Pulse: Up to 200 μJ
- Repetition Rate: From single shot to 40 MHz
- Beam Circularity: TEM00, M²<1.3Beam Quality
- Long Term Mean Power Stability: < 1 % rms over 100 hours
- Warm-up Time: < 30 min
- Dimensions: 120 x 42 x 15 cm
- Weight: Laser Head 93 kg
- Cooling: Water-cooled

Description:
Tangerine is a fiber laser with picosecond pulse width output, designed by Amplitude Laser. The fiber laser was designed for applications in ultrafast science, microelectronics, medical device manufacturing, micro-machining, and particle acceleration. Pulse duration from 350 fs to 10 ps with pulse repetition interval from single shot to 2 MHz. M2 beam quality is <1.3. Fiber laser output is 1030nm, with output energy up to 200µJ.

Versatile and full-featured, the Tangerine femtosecond laser is notably equipped with SuperSync Control for getting more precise synchronization with a high speed scanning system, and Short Pulse (< 150 fs pulsewidth). This laser can also be associated with a large range of add-ons such as industrial frequency conversions down to deep UV, tunable Mango OPA platform and Non-Linear Compression to achieve pulse duration from < 100 fs down to the few cycle regime, ideally suited to generate high flux XUV radiations and attosecond pulses.
