1560nm, 1nJ Femtosecond Fiber Laser

Menlo Systems ELMO HIGH POWER
1560nm Femtosecond Laser
1nJ Pulse

Typical Specifications:
- Center Wavelength: 1560 nm ± 30 nm
- Average Power: >100 mW (up to 200mW)*
- Pulse Energy: >1.0 nJ
- Pulse Width: chirped <90 fs
- Repetition Rate: 100 MHz (50-100 MHz with VARIO)*
- Output Port: fiber-coupled, SC/APC
- Dispersion Management: dispersion can be factory set to achieve short pulses after 1-10 m of additional fiber
- 2nd Fiber-Coupled Seed Port: yes

Description:
Femtosecond fiber laser from Menlo Systems. Key features of the fiber laser include High Stability Low Amplitude and Phase Noise, All-PM Solution, Single Mode-Lock State, figure 9® Technology and Laser Output in Less than 60 Seconds after Pressing On-Button. Optional features of the laser are High Power, User-Defined Repetition Rate, and Additional Seed Ports. Applications include Amplifier Seeding, THz Generation & THz Physics and Ultrafast Spectroscopy. Output Power up to 200 mW in High Power Configuration with a Repetition Rate 50-100 MHz. Fiber laser output wavelength is 1560nm with output power greater then 1mW.
