1555nm Narrow Linewidth Erbium Laser

This Erbium fiber doped laser features a wavelength of 1550 nm and a maximum output power of 15 W. This fiber laser was designed to achieve single longitudinal mode with ultra-low phase noise and RIN. Optional features of the CW laser include wavelength tunability and laser frequency modulation.

This laser features a line width can be as low as 3 kHz as measured at -20 dBm and fitted with a Lorentzian model. These KEOPSYS lasers are designed to provide for maintenance free operation over a long life time and are ideal for OEM or laboratory scientific applications. These narrow line width lasers output at 1550nm wavelength with an output power up to 15 watts.

Review of Key Specifications:

Wavelength : 1550 nm

Maximum Output Power : 15 W

Mode of Operation : CW

Thermal Tuning Range : 1000pm (grade 5)

Modulation Bandwidth : 100kHz




Key Applications:
- LIDAR
- Acoustic or seismic sensing
- Atomic cooling / atomic spectroscopy
- Optical tweezing
