1064nm, 1mJ Picosecond Laser

QS Lasers MPL1510-FC
1064nm Picosecond Laser
1mJ Pulse

Typical Specifications:
- Wavelength: 1064 nm
- Pulse energy: 1 mJ
- Typical pulse duration: < 600 ps
- Pulse to pulse energy stability: < 0.5% RMS
- Pulse repetition rate: 1 - 100 Hz
- Beam profile: Bell-shaped, > 85% fit to Gaussian
- Beam divergence: < 4 mrad
- Polarization: Linear, horizontal at 1064 nm
- Spectral linewidth: SLM
- Beam pointing stability: < 40 μrad
- Typical beam diameter: ~1 mm
- Jitter: ~2 μs RMS

Description:
MPL1510 series DPSS passively Q-switched sub-nanosecond lasers deliver high peak powers at 100 Hz repetition rate. Short laser cavity with the fiber pumped technology is fixed on thermo-stabilized and controlled baseplate which gives extremely stable output parameters performance. Small footprint is welcome point for integration into OEM lasers. Sub-nanosecond pulse duration of < 600 ps, high pulse energy more than 1 mJ, variable repetition rate from 1 Hz to 100 Hz covers many applications like pollution monitoring, DNA analysis, supercontinuum generation and many others.
