1030nm, 400mW DPSS Laser

Integrated Optics 1030L-16B
1030nm DPSS Laser
400mW Output Power

Typical Specifications:
- Central Wavelength (typical): 1030 nm
- Power stability, % (peak-to-peak, 8 hrs): 0.05, 0.5, 1.5
- Noise, % (RMS, 20 Hz to 20 MHz): 0.5, 1.5, 15
- Transversal modes: Multiple
- Control interface type: UART
- Operation mode: APC (CW)
- Modulation bandwidth, MHz: N/A
- Input voltage, VDC: 4.8, 5, 5.3
- External power requirement: +5 V DC, 5 A
- Dimensions, mm: 50 x 30 x 18
- Heat-sinking requirement, °C/W: 0.5
- Optimum heatsink temp °C: 15, 20, 30
- Warm up time, mins (cold start): 0.2, 1, 2
- Temperature stabilization: Internal TEC
- Overheat protection: Yes
- Storage temp °C (non-condensing): -10 to 50
- Net weight, kg: 0.1, 0.12, 0.14

Description:
MatchBox laser modules are widely configurable and deliver high-end performance in a miniature package. Smart power electronics is installed in the same enclosure. MatchBox offers highest power density and best performance/price ratio. This 1030 nm laser with an SMA output connector is a very compact high performance laser source for multimode fiber installations. Fiber could be supplied optionally.
