1030nm, 20W Femtosecond Pulse Laser

Amplitude Laser Satsuma Series
1030nm Laser
20W Output Power

Typical Specifications:
- Average Power: > 20 W
- Pulse Width: < 350 fs to > 10 ps
- Central Wavelength: 1030 +/- 5 nm
- Energy Per Pulse: > 10 μJ, > 20 μJ, > 40 μJ / 150 μJ* (High Energy Option)
- Repetition Rate: From single shot to 40 MHz
- Beam Circularity: > 87 %
- Beam Pointing Stability: < 25 μrad/°C
- Long Term Mean Power Stability: < 1 % rms over 100 hours
- Warm-up Time: < 30 min

Description
The Satsuma family of femtosecond laser offers versatility in the most compact aircooled laser platform on the market. Satsuma is a cost-efficient solution providing high repetition rate and high energy, up to 150 μJ.
Versatile and full-featured, Satsuma femtosecond lasers are equipped with: FemtoBurst™ (choose number of pulses, rhythms, time between each pulse from 25 to 100 ns); the trigger on demand for selecting individual pulses, and SuperSync Control for getting more precise synchronization with a high speed scanning system. Satsuma femtosecond laser is available with green, UV and deep UV outputs.
