Home  >  Nanosecond Lasers  >  Amonics  >  FL-1064NM-10W



High Peak Power 1064nm Fiber Laser; CW and Nanosecond Pulse Modes

  • Fiber Laser, 1064nm, 10kW Power

Request Quote   Ships: Request current lead time | Model FL-1064NM-10W

Key Features
  • Up to 10kW peak pulse power; up to 10W CW output power
  • Fully Featured Benchtop Laboratory R&D Instrument
  • CW and Pulsed Modes of Operation
  • Optical Feedback Protection

Price and Delivery Quote

You will receive factory-direct price with no mark-ups

Technical Questions for this Product

ASK AN ENGINEER

Questions route directly to the correct Product Engineer

Customers Also Considered:

MODEL FL-1064NM-10W
PRICE Request Price
OPTICAL
  • Wavelength: 1064 nm (+/-1 nm)
  • User Adjustable Output Power (CW): 0 to +40 dBm (10W)
  • Factory Pre-Set Pulse Width: 10 to 1,000 nanoseconds
  • Factory Pre-Set Repetition Rate: 10 to 100 kHz (external TTL)
  • Spectral Line Width (typical): 0.2nm
  • Polarization: Linear (random on request)
APPLICATIONS
  • Laboratory Research
  • Micromachining Applications
  • Marking Applications
  • Scribing
  • Fiber Optic Sensing
INTERFACE
  • Front Panel: Alphanumeric Color Front Panel Interface
  • Remote: RS232, LabView control software included
  • Remote: RJ-45 (TCP/IP Ethernet optional)
  • Optical Connector Options: FC/APC, FC/UPC, SC/APC, SC/UPC
  • Optical Fiber Options: PM fiber (SMF-28 optional)
GENERAL
  • Operating Temperature Range: 0 to +40C
  • Storage Temperature: -10 to +70C
  • Power Supply: 90 – 240 VAC, 47 – 63Hz
  • Dimensions: 3U Rackmount, 450(W) x 615(D) x 150(H) mm
  • Chassis Safety Control: Key-lock switch, BNC
  • Interlock Key

Product Overview:

These 1064nm Ytterbium Doped Fiber Lasers offer up to 10kW of peak power and 10W of average power. They offer both a front panel and a PC interface. These turn-key microprocessor controlled benchtop / rack mount units are burn-in tested and are highly reliable with multiple integrated protection features.
