350nm-1150nm, 3.2nm Miniature VIS Spectrometer

StellarNet VIS Spectrometer
350nm-1150nm Spectral Range
3.2nm Resolution

Typical Specifications:
- Wavelength range: 350-1150 nm
- Detector type: CCD or PDA, 2k/3k pixels
- Pixel size: 14 x 200um or 7 x 200um
- Grating g/mm: 600
- Slit size options: 14, 25, 50, 100, 200um
- Predicted slit resolutions (nm): 6.0 (200 um), 3.2 (100 um), 1.6 (50 um), 1.00 (25 um), 0.80 (14 um)
- Spectrograph: f/4, SymX-Czerny–Turner
- Fiber optic input: SMA905 0.22na single fiber
- Order sorting filters: Integrated & High Pass
- Dynamic range: 2000:1 with 6 decades
- Stray light: <.1% at 435nm;<.05% at 600nm
- Signal to noise: 1000:1
- Detector integration: 1ms to 65s
- Power consumption: < 100 mA via USB port
- Interface: USB-2 or USB-2 Hub
- Operating systems: Windows
- Software included: SpectraWiz program & apps
- LED spectra of red, green, blue, white
