220nm-400nm, 0.3nm UV Spectrometer

Pembroke Qmini Spectrometer
220nm-400nm Spectral Range
0.3nm Resolution

Typical Specifications:
- Measurement range: 0.1-1000 µm
- Light source: He-Ne laser (633 nm)
- Detector: Silicon photodiode
- Sample volume: 0.2 mL
- Measurement time: 30 seconds
- Power supply: 100-240 VAC, 50/60 Hz
- Dimensions: 20 cm x 20 cm x 12 cm
- Weight: 2.5 kg
- Focal length: 75 mm
- Spectral resolution: 0.1 nm
- Refractive index range: 1.33-1.70
- Temperature range: 10-50°C
- Humidity range: 10-90% RH (non-condensing)

Description:
Ultra-Compact UV Spectrometer with resolution of 0.3nm over a spectral range of 220nm-400nm is offered by Pembroke Instruments. The UV spectrometer small size does not limit it in features with a powerful auxiliary connect which supports trigger input, shutter, flash lamp control and can be used as a general I/O. Remote interface is possible by USB (Standard) or optional Ethernet, WLAN, Bluetooth or CAN. The QMini Spectrometer from Pembroke Instruments also has a user changeable slit interface to support different resolutions and sensitivity. High performance compact UV spectrometer from Pembroke Instruments.
