Home  >  Wavelength Meters  >  Yokogawa  >  AQ6151



Wavelength Meter, 1270nm-1650nm

Request Quote
sku / item#: AQ6151
ships: 7 days

Key Features
  • High wavelength accuracy of ±1 pm
  • Single and Multiple Wavelength Modes
  • Optical Spectrum View
  • Real-time wavelength correction

Customers Also Considered:

Why do Scientists & Engineers Choose Laser Lab Source?

MODEL AQ6151
PRICE Request Price
SPECIFICATIONS
  • Wavelength range: 1270 to 1650 nm
  • Wavelength accuracy: ±1 pm at 1550 nm
  • Display resolution: 0.0001 nm
  • Power accuracy: ±0.5 dB (1550 nm, -10 dBm)
  • Linearity: ±0.3 dB (1550 nm, -30 dBm or higher)
  • Polarization dependency: ±0.5 dB (1550 nm)
  • Display resolution: 0.01 dB
  • Maximum number of wavelengths: 1024
  • Minimum input power: -40 dBm (1270 to 1600 nm, single line input)
  • Safe maximum input power: +18 dBm (total of all lines)
  • Return loss: 35 dB
  • Measurement time: 0.3 s or less (single measurement)
  • Functions Measurement: Single, repeat, average, drift, data logging
  • Display: single wavelength, multi wavelength, delta, grid, spectrum (with zooming)
  • Data analysis: Peak search, FP-LD analysis, drift analysis, WDM (OSNR) analysis
  • File Saving/loading: measured results (CSV), saving/loading setup parameters (binary), saving screen images (BMP)
  • Display: 5.7-inch color LCD (640×480 dots)
  • Interfaces: GPIB, ETHERNET, USB, VGA

Product Overview:

These Yokogawa wavelength meters measure lasers over the wavelength range of 1270nm-1650nm with up to +/-0.2 ppm accuracy. Designed for applications in WDM transmission systems, lasers / optical transceivers, and calibration of test systems. This wave meter has user friendly features with easy to view bright color LCD, proven design, direct operation with a mouse, data access through LAN and USB ports. The USB ports can be used for data storage, mouse, or keyboard. Measurements can be viewed in many modes including single or multiple wavelength modes, delta wavelength, grid or optical spectrum view. The wavelength meter can also measure power in dBm, mW, or µW and display wavelength in nm, THz), or cm-1. High wavelength accuracy of ±0.3 pm. There are two models in the series. The high accuracy AQ6151 model offers an accuracy of ± 0.3pm to meet the most demanding precision requirements. The standard accuracy AQ6150 offers a ± 1pm accuracy for applications with less demanding requirements at a more affordable price. The real time correction feature utilizes a highly stable reference signal from the built-in wavelength reference light source in order to provide long-term stability for each and every measurement taken.
